Mercury 30 Service Manual

90-826148R2 MARCH 1997 ELECTRICAL - 2A-9
ELECTRICAL (S/N-USA-0G380075 THRU 0G589999/
BEL-MANUAL-9928508/BEL-ELEC-9928481 THRU 9973099)
REF.
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb. in. lb. ft. N·m
1 5 SCREW (M5 x 30) MANUAL 50 5.6
2 1 STATOR
3 1 O RING
4 1 TRIGGER
5 1 SOLENOID ASSEMBLY
6 2
BUSHING
7 2 GROMMET
8 2 NUT (8-32)
9 2 SCREW (M6 x 25) ELECTRIC 40 4.5
10 2 NUT (1/4-20) 50 5.6
11 2 LOCKWASHER
12 1 INSULATOR (RED)
13 1 RETAINER (ELECTRIC HANDLE)
14 1 SCREW
15 1 BATTERY CABLE (NEGATIVE–ELECTRIC)
16 2 CDM ASSEMBLY
17 2 HI-TENSION CABLE
18 1 BOOT
19
2 SPARK PLUG (NGK# BP8H-N-10) 240 20 27.1
19
2 SPARK PLUG (NGK#BPZ–8H–N–10) 240 20 27.1
20 4 SCREW (M6 x 14) 80 9.0
21 1 PLATE–Electrical
22 1 CABLE (MANUAL)
23 1 SCREW (M6 x 14) 80 9.0
24 1 SCREW (M5 x 12)(ELECTRIC)
25 1 SCREW (M8 x 12)(MANUAL)
26 6 BUSHING
27 3 GROMMET DESIGN I
28 3 SCREW (M6 x 30)
29 3 BUSHING–Flanged
30 3 GROMMET DESIGN II
31 3 WASHER
32 3 SCREW (M6 x 35) 100 11.3
33 1 TPM ASSEMBLY
34 3 SCREW (M5 x 20) 80 9.0
35 3 STA–STRAP
36 1 VOLTAGE REGULATOR ELECTRIC
37 2 SCREW (M6 x 35) 80 9.0
38 1 CONDUIT
39 1 TERMINAL BLOCK
40 2 SCREW (10–16 x 3/8 IN.) MANUAL
41 2 SCREW (M5 x 12)
42 1 HARNESS ASSEMBLY–Engine (MANUAL)
43 1 HARNESS ASSEMBLY–Engine (ELECTRIC)
44 1 HARNESS (ELECTRIC)
