Mercury 30 Service Manual

90-826148R2 MARCH 1997 ELECTRICAL - 2A-11
ELECTRICAL COMPONENTS
(S/N-USA-0G590000/BEL-9973100 & ABOVE)
REF.
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb. in. lb. ft. N·m
1 5 SCREW (M5 x 30) 50 5.6
2 1
STATOR MANUAL
3 2 PLUG
4 1 TRIGGER
5 1 CABLE TIE (4 IN.)
6 1 SOLENOID ASSEMBLY
7 2 BUSHING
8 2 GROMMET
9 2 NUT (8-32)
10 2 SCREW (M6 x 25) ELECTRIC 40 4.5
11 2 NUT (1/4-20) 50 5.6
12 2 LOCKWASHER
13 1 INSULATOR (RED)
14 1 RETAINER (ELECTRIC HANDLE)
15 1 SCREW
16 1 BATTERY CABLE (NEGATIVE–ELECTRIC)
17 2 CDM ASSEMBLY
18 2 HI-TENSION CABLE
19 1 BOOT
20 2 SPARK PLUG (NGK# BP8H-N-10) 240 20 27.1
21 2 SPARK PLUG (NGK#BPZ–8H–N–10) 240 20 27.1
22 1 CABLE MANUAL
23 1 SCREW (M8 x 12)
24 4 SCREW (M6 x 14) 60 6.7
25 1 PLATE–Electrical
26 1 SCREW (M5 x 12) 60 6.7
27 1 WASHER
28 1 SCREW (M6 x 14) 60 6.7
29 1 WASHER
30 6 BUSHING
31 3 GROMMET
32 3 SCREW (M6 x 30)
33
1 REV LIMITER (MANUAL)
33
1 REV LIMITER (ELECTRIC)
34 2 SCREW (M6 x 25) 30 3.4
35 4 STA–STRAP (8 IN.)
36 1 VOLTAGE REGULATOR
37 2 SCREW (M6 x 35) ELECTRIC 60 6.7
38 1 CONDUIT
39 1 HARNESS ASSEMBLY–Engine (MANUAL)
40 1 HARNESS ASSEMBLY–Engine (ELECTRIC)
41 1 CONDUIT
1 POWERHEAD

Mercury 30 Specifications

General

Horsepower	30 HP
Cylinders	3
Displacement	526 cc
Gear Shift	F-N-R
Fuel Induction System	Electronic Fuel Injection (EFI)
Shaft Length	20 in
Steering	Remote / Tiller
