Mercury 30 Service Manual

90-826148R2 MARCH 19972A-26 - ELECTRICAL
CAPACITOR DISCHARGE MODULE RESISTANCE CHECK - DIGITAL METER
Connect Positive (+)
Meter Lead To:
Connect Negative (–)
Meter Lead To:
Ohms
Scale
Results:
Ground Pin (A)/ or Black
Test Harness Lead
White (C)/ or White Test
Harness Lead
Ω or 2K 1.125-1.375 KΩ
Green (D)/ or Green Test
Harness Lead
Ground Pin (A)/ or Black
Test Harness Lead
OL or OUCH
Ground Pin (A) or Black
Test Harness Lead
Green (D)/ or Green Test
Harness Lead
.400-.900
Green (D)/ or Green Test
Harness Lead
Black/Yellow (B)/ or Black/
Yellow Test Harness Lead
.400-.900
Black/Yellow (B)/ or Black/
Yellow Test Harness Lead
Green (D)/ or Green Test
Harness Lead
OL or OUCH
Spark Plug Terminal
(At Spark Plug Boot)
Ground Pin (A) or Black
Test Harness Lead
Ω or 2K .950-1.150 KΩ
NOTE: Due to the differences in test meters battery polarity, results other than specified may be obtained. In
such a case, reverse meter leads and re-test. If test results then read as specified on all tests CDM is O.K.. The
diode measurements above will be as specified if using a Fluke equivalent multimeter.

Mercury 30 Specifications

General

Horsepower	30 HP
Cylinders	3
Displacement	526 cc
Gear Shift	F-N-R
Fuel Induction System	Electronic Fuel Injection (EFI)
Shaft Length	20 in
Steering	Remote / Tiller
