DRIVE SYSTEM AND ENGINE INSTALLATION SECTION - 6
Page 44 / 54 90-899883183 DECEMBER 2007
8. Lubricate the sterndrive U‑joint O‑rings and drive shaft splines. A grease packet for this
procedure is provided with the sterndrive packaging.
a
a
b
7853
a - U‑joint O‑rings b - Drive shaft splines
Tube Ref No. Description Where Used Part No.
91
Engine Coupler Spline Grease Ujoint O-rings 92-802869A 1
Tube Ref No. Description Where Used Part No.
91
Engine Coupler Spline Grease Drive shaft splines 92-802869A 1
9. Ensure that the U‑joint bellows are clean.
a
7854
a - U‑joint bellows
