Microhard Systems BulletPlus - Message Structure

© Microhard Systems Inc. 141
4.0 Configuration
Remote Port
Specify the UDP port number of the Remote IP Address.
*Default Port Numbers for Microhard NMS (20100 for modem events, 20200 for
Management)
Values (Port #)
20200
Interval Time(s)
This is the interval time in seconds, that the BulletPlus will send the
configured UDP message to the Remote IP and Port specified.
Values (seconds)
600
4.11.4.2 Event Report > Message Structure
Modem_event message structure
- fixed header (fixed size 20 bytes)
- Modem ID (uint64_t (8 bytes))
- Message type mask (uint8_t(1 byte))
- reserved
- packet length (uint16_t(2 bytes))
Note: packet length = length of fixed header + length of message payload.
Message type mask
Modem info - 2 bits
00 no
01 yes (0x1)
Carrier info - 2 bits
00 no
01 yes (0x4)
WAN Info - 2 bits
00 no
01 yes (0x10)
sdp_event message structure
- spd_cmd (1 byte(0x01))
- content length (1 byte)
- spd_package - same as spd response inquiry package format
Message Info Type
When Modem_Event is selected, up to three different payloads can be
selected.
Values (seconds)
Modem
Carrier
WAN
