4.0 Configuration
4.11.4.3 Event Report > Message Payload
Modem info:
Content length - 2 BYTES (UINT16_T)
Modem name - STRING (1-30 bytes)
Hardware version - STRING (1-30 bytes)
Software version - STRING (1-30 bytes)
Core temperature - STRING (1-30 bytes)
Supply voltage - STRING (1-30 bytes)
Local IP Address - 4 BYTES (UINT32_T)
Local IP Mask - 4 BYTES (UINT32_T)
Carrier info:
Content length - 2 BYTES (UINT16_T)
RSSI - 1 BYTE (UINT8_T)
RF Band - 2 BYTES (UINT16_T)
3G_Network - STRING (1-30 Bytes)
Service type - STRING (1-30 Bytes)
Channel number - STRING (1-30 Bytes)
SIM card number - STRING (1-30 Bytes)
Phone number - STRING (1-30 Bytes)
WAN Info:
Content length - 2 BYTES (UINT16_T)
IP address - 4 BYTES (UINT32_T)
DNS1 - 4 BYTES (UINT32_T)
DNS2 - 4 BYTES (UINT32_T)
Message Order:
Messages will be ordered by message type number.
For example,
If message type mask = 0x15, the eurd package will be equipped by header+modem information+carrier
information+wanip information.
If message type mask = 0x4, the eurd package will be equipped by header+carrier information.
If message type mask = 0x11, the eurd package will be equipped by header+modem infomation+wanip
infomation.
a fixed message tail
content length --- 2 BYTES(UINT16_T)
product name --- STRING(1—64 bytes)
image name --- STRING(1—64 bytes)
domain name --- STRING(1—64 bytes)
domain password --- STRING(32 bytes) // MD5 encryption
module list --- 5 BYTES // radio, ethernet, carrier, usb, com
