3.0 Hardware Features
3.1 BulletPlus
The BulletPlus is a fully-enclosed unit ready to be interfaced to external devices with standard connectors
as discussed below. An optional mounting bracket can be ordered to allow the BulletPlus to be mounted
for a fixed installation.
The BulletPlus Hardware Features Include:
 Standard Connectors for:
 3x 10/100 Ethernet Ports (RJ45 - 1xWAN / 2xLAN)
 Data Port (RS232/DB9)
 4-Pin: MATE-N-LOK Type Connector for Power / I/O 1/2
 Cellular Antenna (SMA Female Antenna Connection x2)
 GPS Antenna (SMA Female Antenna Connection)
 WiFi Antenna (RP-SMA Female Antenna Connection)
 Status/Diagnostic LED’s for RSSI(x3), Tx, Rx, GPS, CPU
 Dual SIM (Mini-SIM (2FF)) Card Slots
 CFG Button for factory default / firmware recovery operations
 USB 2.0 Connector
Image 3-1: BulletPlus
