About the control group screens 163
PRO6 Live Audio System
Owner’s Manual
About the control group screens
Each type of control group
screen has — apart from the
channel strip, which is
common to most screens —
two main areas (shown
right). The management
section at the top allows
you to choose the group
members, and is common
to all control group types.
While the bottom section
contains the controls and
sections specific to each
type, which are described
later on in this chapter.
Management section
The group management section of each control group screen has two main panels. The
left panel has five group-dependent lists of channels/mixes from which you can choose
group members. The right panel contains the current group members (the example
below shows a VCA group). Group members are moved between the two main panels
using the ADD and REMOVE buttons.
Management
section
(common)
Group-
specific
section
1 Panels of group-dependent lists. Contains
inputs, returns, auxes, matrices and masters
from which to add members to the selected
group.
Some may be blanked out, as they are
dependent on group type. Use the slider on
the right of a panel, where appropriate, to
access all non-members.
2 Name of selected group.
3 Group member panel, shows the current
group members.
4 ADD button, adds the selected
non-members to the group member panel and,
therefore, to the group.
5 REMOVE button, moves members from
the group member panel to their respective
lists; they are no longer members of the
group.
1
2
3
4
5
