336 Appendix B: Technical Specification
PRO6 Live Audio System
Owner’s Manual
PRO6 status functions
Meters
Screens
Screen functions
LCD switches
Control Centre meters 9 x output 20-LED -36dBu to +21dBu
16 x input 20-LED -36dBu to +21dBu
32 x gain reduction 7-LED
Screen metering 105 x 20-segment signal level meters
112 x 7-segment gain reduction (or 144 including
aux and matrix gain reduction meters for the
compressors)
Quantity 2 x full-colour daylight-viewable screens
Size 15” (diagonal)
Resolution 1024 x 768 pixels
External screen 2 x output connectors for remote screens
Source Each screen can be switched to source either the
local control centre or an external input
KVM Screen 2 can be switched to operate up to 3 external
computers utilising the control centre trackball and
keyboard
Internal GUI Advanced interpolated graphics support all control
centre functions
Quantity 33 x RGB colour display switches
Size 18 mm x 12 mm display area
Resolution 36 x 24 pixels
