This section shows the linked parameters of the return channels.

Input controls

The following diagram shows the parameters of the input controls affected by stereo

linking.

* Applies to tape and primary inputs.

Direct output

Not applicable.

Item Control Parameter

1 48V switch* 48V phantom voltage in/out

2 Flt switch* 30Hz filter in/out

Configuration

processing area in

GUI channel strip

DL351 Modular I/O

analogue input card

Mic splitter

channel

Line I/O analogue

input channel
