PRO6 system inputs and outputs 325
PRO6 Live Audio System
Owner’s Manual
PRO6 system inputs and outputs
DL351 I/O Box
Analogue inputs
Analogue outputs
Digital inputs
Digital outputs
Analogue Jack inputs and outputs
MIDI and GPIO
Connector 3-pin XLR balanced
A/D converter 24-bit, 96k and 128 times over sampling
Connector 3-pin XLR balanced
D/A converter 24-bit, 96k and 128 times over sampling
Connector AES3 (two channels of digital audio) on 3-pin XLR
Sample rates Accepts any frequency between 32k to 96k
Bypass Sample rate converter can be bypassed
Connector AES3 (two channels of digital audio) on 3-pin XLR
Sample rates 48k, 96k or auto tracking to inputs
Bypass Sample rate converter can be bypassed
Word length 16-, 20- or 24-bit
Connector 16 x 1/4” TRS (8 x inputs (returns) and 8 x outputs
(sends))
Miscellaneous Balanced, normalising and low latency
MIDI connector In, out and through on 5-pin DIN
GPIO IN connector 25-pin D-type (opto isolated)
GPIO OUT connector 25-pin D-type (opto isolated)
