Midas PRO6 User Manual

326 Appendix B: Technical Specification
PRO6 Live Audio System
Owner’s Manual
Digital system inputs and outputs
DL451 I/O Box (option)
Analogue inputs
Analogue outputs
Digital inputs
Digital outputs
MIDI and GPIO
Digital system inputs and outputs
System connector 3 x AES50 (24 channels of bi-directional digital
audio) on EtherCon® XLR
N+1 connector 1 x AES50 (24 channels of bi-directional digital
audio) on EtherCon® XLR providing redundant back
up
Connector 3-pin XLR balanced
A/D converter 24-bit, 96k and 128 times over sampling
Connector 3-pin XLR balanced
D/A converter 24-bit, 96k and 128 times over sampling
Connector AES3 (two channels of digital audio) on 3-pin XLR
Sample rates Accepts any frequency between 32k to 96k
Bypass Sample rate converter can be bypassed
Connector AES3 (two channels of digital audio) on 3-pin XLR
Sample rates 48k, 96k or auto tracking to inputs
Bypass Sample rate converter can be bypassed
Word length 16-, 20- or 24-bit
MIDI connector In, out and through on 5-pin DIN
GPIO IN connector 25-pin D-type (opto isolated)
GPIO OUT connector 25-pin D-type (opto isolated)
System connector AES50 (24 channels of bi-directional digital audio) on
Ethercon XLR
Duplicate connector AES50 (24 channels of bi-directional digital audio) on
Ethercon XLR providing dual redundant back up of
channels
