PRO6 Live Audio System
Owner’s Manual
PRO6 input and output characteristics
Analogue input characteristics
Analogue output characteristics
Digital I/O characteristics
Input Type Load Z Gain Max. Level Connector
DL351 I/O Box 10K -25dB to +60dB +26dBu XLR
Surface I/O 10K -25dB to +60dB +26dBu XLR
DL451 I/O Box 10K -25dB to +60dB +26dBu XLR
DL431 Splitter 10K -22.5dB to +65dB +24dBu XLR
Talk mic 600R +15dB to +60dB +6dBu XLR
Monitor 10K 0dB +24dBu XLR
Output Type Source Z Gain Max. Level Connector
DL351 I/O Box 50R 0dB +21dBu XLR
Surface I/O 50R 0dB +21dBu XLR
DL451 I/O Box 50R 0dB +21dBu XLR
DL431 Splitter
Main
150R 0dB +24dBu XLR
DL431 Splitter
Isolated
75R -6dB +18dBu XLR
Talk mic 50R 0dB +24dBu XLR
Monitor 50R 0dB +24dBu XLR
Headphones 10R +10dB 750mW ¼” Jack
Type Chan. Data
Length
I/O Description Notes Conn.
AES3 2 24-bit Input Conforms to
AES3 - 2003
XLR
AES3 2 24-bit Output Conforms to
AES3 - 2003
XLR
AES50 24 24-bit Bi-directional Conforms to
AES50 -2006
Ethercon
XLR
HyperMac 192 24-bit Bi-directional Cat 5e, Gigabit Ethernet
physical layer
Ethercon
XLR
HyperMac 192 24-bit Bi-directional 850 nm, laser module
1.25Gb/s 1000 base-SX
physical layer on 50/125
multimode fibre
Opticon XLR
