330 Appendix B: Technical Specification
PRO6 Live Audio System
Owner’s Manual
Control data system inputs and outputs
Miscellaneous inputs and outputs
System connector Ethercon XLR
Duplicate connector Ethercon XLR providing dual redundant back up
Word clock IN connector BNC
Word clock OUT connector BNC
AES3 sync IN connector 3-pin XLR
AES3 sync OUT connector 3-pin XLR
External (Ethernet) connector Ethercon XLR
Monitor input connector 3-row, 15-pin D-type, analogue VGA
KVM input connection Screen 3-row, 15-pin D-type (analogue VGA) and
USB keyboard/mouse
USB host connection
Line I/O + Mic Splitter
USB 2.0 full speed (12.0Mbs)
500mA maximum load
USB slave connection
Line I/O + Mic Splitter
USB 2.0 full speed (12.0Mbs)
USB host connection
Surface
USB 2.0 full speed (12.0Mbs)
1A maximum load
