Midas PRO6 User Manual

PRO6 system inputs and outputs 329
PRO6 Live Audio System
Owner’s Manual
PRO6 Control Surface
Analogue audio system inputs
Analogue audio system outputs
Digital audio system inputs and outputs
Connector 3-pin XLR balanced
A/D converter 24-bit, 96k and 128 times over sampling
Connector ¼” Jack balanced
A/D converter 24-bit, 96k and 128 times over sampling
Talkback connector 3-pin XLR balanced line
Talk connector 3-pin XLR balanced mic with 48V phantom voltage
Meters (quantity 16) 20-segment -36dBu to +21dBu
Connector 3-pin XLR balanced
D/A converter 24-bit, 96k and 128 times over sampling
Connector ¼” Jack balanced
D/A converter 24-bit, 96k and 128 times over sampling
Monitor connector 3-pin XLR balanced line
Talk connector 3-pin XLR balanced line
Headphone connector ¼” Jack (stereo)
Meters (quantity 9) 20-segment -36dBu to +21dBu
Input connector AES3 (two channels of digital audio) on 3-pin XLR
Sample rates Accepts any frequency 32k to 96k
Bypass Sample rate converter can be bypassed
Output connector AES3 (two channels of digital audio) on 3-pin XLR
Sample rate 48k, 96k or auto tracking to inputs
Bypass Sample converter can be bypassed
Word length 16-, 20- or 24-bit
System expansion connector 3 x AES50 (24 channels of bi-directional digital
audio) on Ethercon XLR
Snake connector (copper) HyperMac (192 channels of bi-directional digital
audio) on Ethercon XLR
Duplicate snake connector
(copper)
HyperMac (192 channels of bi-directional digital
audio) on Ethercon XLR
Snake connector (fibre) HyperMac (192 channels of bi-directional digital
audio) on Opticon XLR
Duplicate snake connector
(copper)
HyperMac (192 channels of bi-directional digital
audio) on Opticon XLR
