328 Appendix B: Technical Specification
PRO6 Live Audio System
Owner’s Manual
DL371 DSP/Router
System inputs and outputs
Miscellaneous inputs and outputs
System connector 3 x AES50 (24 channels of bi-directional digital audio) on
EtherCon® XLR
N+1 connector 1 x AES50 (24 channels of bi-directional digital audio) on
EtherCon® XLR providing dual redundant back up
System expansion connector 4 x AES50 (24 channels of bi-directional digital audio) on
EtherCon® XLR
Snake connector (copper) HyperMac (192 channels of bi-directional digital audio) on
EtherCon® XLR
Duplicate snake connector (copper) HyperMac (192 channels of bi-directional digital audio) on
EtherCon® XLR
Snake connector (fibre) HyperMac (192 channels of bi-directional digital audio) on
OpticalCon® XLR
Duplicate snake connector (fibre) HyperMac (192 channels of bi-directional digital audio) on
OpticalCon® XLR
Word clock IN connector BNC
Word clock OUT connector BNC
AES3 Sync IN connector 3-pin XLR
AES3 Sync OUT connector 3-pin XLR
External connector EtherCon® XLR
