PRO6 Live Audio System
Owner’s Manual
Chapter 14: Monitors And
Communications
This chapter describes the monitoring and communications functions of the PRO6.
Monitors (A and B)
To match the two-bus solo system there are two monitor outputs, A and B, which
control their respective output levels. These are controlled from the monitor section on
the master bay as shown in the following diagram. Each monitor output has:
• The ability to monitor mono and stereo outputs, and an external input.
• An external talkback input.
• A local monitor output.
• A headphone output.
•Delay compensation.
• Control of the solo buses.
Monitor A and B
output panel
meters
Monitor A and B
output panel
