426 Appendix L: Parameters Affected By Automate Patching
XL8 Live Performance System
Owner’s Manual
System devices
Sources for the outputs of external devices,
such as the DL351 Modular I/O, DL451
Modular I/O, DN9696 Recorder, etc., can be
changed per scene. The sources are selectable
via the Stage I/O and FOH I/O tabs in To
section of the Patching screen.
However, this does not include the I/O card
configuration.
Monitors
The following monitor sources, shown on the Monitors screen (see below), can be
changed per scene.
Item Parameter
1 Talk input source
2 Taklback input source
3 PFL direct input source
4 AFL direct input left source
5 AFL direct input right source
6 External monitor input left source
7 External monitor input right source
