Aux Sends (aux channels) 557
XL8 Live Performance System
Owner’s Manual
Aux Sends (aux channels)
This section shows you which parameters for each of the 16 aux channels are affected
by copy through scenes.
Config sections
The following diagram shows the parameters of the configuration processing area
copied through scenes.
Item Control Parameter
1 Control knob Direct input level
2 MUTE switch Direct input mute on/off
3 B switch Direct input solo B in/out
4 PRE switch Direct input pre- in/out
1
4
3
Insert and configuration
processing area in GUI
channel strip
aux send
overview in GUI
channel strip
2
3
