About the crossfade Edit Event window 207
PRO6 Live Audio System
Owner’s Manual
Using a crossfade mute
The Mute option of the Parameters list lets you initiate a mute at the end of a
crossfade down operation. For example, if you set a crossfade of two seconds, the
mute will turn on after this time has expired (provided it was off). If the crossfade is a
‘crossfade up’, the mute will turn off during the crossfade up time (provided it was on).
Crossfade set up section in the Edit Event window
The crossfade set up section, which is at the bottom of the Edit Event window, is
where you set up how the crossfade operates. Here you can set up the duration of the
crossfade and the rate at which it occurs. You can configure two crossfade rates per
crossfade or keep its rate constant throughout.
Figure 24: Crossfade set up section
7 centre level control
knob
Centre
8 LFE level control
knob
Sub
9 MUTE switch Mute
Item Description
1 % of Travel field, sets the initial travel distance of the control as a
percentage of the total distance of travel.
2 % of Time field, sets the time for the initial travel of the control as a
percentage of the overall time.
3 Faders Down field, sets the time taken for the total travel (milliseconds) of
the control for a ‘fader down’ (or whichever control is used) crossfade
event. For the Faders Up field, this sets the time taken for the total travel
(milliseconds) of the control for a ‘fader up’ crossfade event.
4 Section for setting the crossfade down parameters.
5 Section for setting the crossfade up parameters.
6 Graph of up/down crossfade.
Item Control Parameter option
Time
Control up travel
Control down travel
3
2
1
45
6
