Midas PRO6 User Manual

240 Chapter 28: Delay Compensation (Latency)
PRO6 Live Audio System
Owner’s Manual
Monitor mix (low latency)
The following table shows the delay compensation settings for this mix.
The following signal path examples all measure the same latency of 176 samples at
96kHz = 1.83ms:
• FOH XLR – IP – MAST – XLR
• XLR – IP – MAST – XLR
• XLR – IP – MTX – XLR
• XLR – IP – MAST – MTX – XLR
• XLR – IP – AS – XLR
• XLR – MAST DI (Input) – XLR
• XLR – MTX DI (Input) – XLR
• XLR – AS DI – AS – XLR
• XLR – AR (Input) – MAST – XLR
• XLR – AR (Input) – MAST – MTX – XLR
• XLR – AR (Input) – AS – XLR
Option On/off status
Master to Matrix Post-processing Off
Input Channels
Insert Off
Aux Sends
Monitor Mode (Align with Masters)
Insert
Send-FZ-Return
Graphic EQ
On
Off
Off
Off
Master and Matrix
Insert
Graphic EQ
Off
Off
