388 Appendix K: Parameters Affected By Scope
XL8 Live Performance System
Owner’s Manual
Matrix send
The following diagram details the scoped matrix send parameters in the input channels.
Although it only shows matrix buses 1 to 8, it also applies to matrix buses 9 to 16.
* Bus send levels/panning can also be adjusted via the input channel overview
(GUI channel strip) by using drag in the aux and matrix panels.
You can scope individual bus sends. In column B (All), all sends are affected, and in
column F (Busses), individual sends can be scoped.
ABC E DFG H
Item Parameter
1 Send level* N/A Yes N/A N/A N/A Yes N/A N/A
2 Send pan*
N/A Yes N/A N/A N/A Yes N/A N/A
3 Send pre-fader on/off
N/A Yes N/A N/A N/A Yes N/A N/A
4 Send on/off
N/A Yes N/A N/A N/A Yes N/A N/A
A
B
C
D
E
F
G
H
4
3
4
3
1/2
4
3
4
3
4
3
4
1
3
GUI input
fast strip
Matrix buses
processing area in
GUI channel strip
