Midas PRO6

Inputs 433
XL8 Live Performance System
Owner’s Manual
MIC safe
The following diagram details the parameters in the inputs protected by MIC safe.
Item Control Parameter
1 stage box control
knob*
Gain of remote amplifier
2 48V switch 48V phantom gain
3 30Hz switch 30Hz filter
4 gain trim control
knob*
Digital input trim
5 Delay control knob Delay time
6
Ø switch
Input phase invert on/off
3
12
4
9
4
3
5
6
1/4
7
8
1
2
10
6
input channel
overview in GUI
channel strip
Configuration
processing area in GUI
channel strip
4
Insert processing
area in GUI
channel strip
10
DL351 Modular I/O
analogue input card
Mic splitter
channel
1
2
1
2
3
1
2
Line I/O analogue
input channel
