Masters
463
XL8 Live Performance System
Owner’s Manual
MUTE safe
The following diagram details the master parameters protected by the
MUTE
safe.
Item
Control
Parameter
1
MUTE
switch
Mute on/off
2
MUTE
switch
Direct input mute on/off
1
1
1
Insert and
configuration
processing area in
GUI channel strip
Fader processing
area in GUI
channel strip
488
490
