Aux 515
XL8 Live Performance System
Owner’s Manual
EQ
The following diagram shows the EQ and GEQ parameters affected by stereo linking.
Item Control Parameter
1 EQ switch EQ on/off
2 gain control knob EQ gain level
3 width control knob EQ width
4 freq control knob EQ frequency
5 SHAPE switch Band 1 shelving mode: bell, warm, high pass 6dB
or high pass 12dB
6 SHAPE switch Band 2 shelving mode: bell or high pass 24dB
2
4
1
EQ processing
area in GUI
channel strip
1
3
2
5/6/7
4
3
2
4
3
2
6
3
2
3
4
4
5
aux send
overview in GUI
channel strip
8
