Matrix 531
XL8 Live Performance System
Owner’s Manual
* Not shown in diagram.
Note: Although bands 1 and 6 are not shown above, the items in the table also apply.
Both bands have items 2, 3 and 4. Band 1 also has item 7, and band 6 also has item 5.
Bus sends
Not applicable.
Master routing
Not applicable.
7* SHAPE switch Band 1 shelving mode: bell, warm, high pass 6dB
or high pass 12dB
8 GEQ All GEQ parameters. (GEQ parameters linked
when both linked channels have a GEQ assigned to
them.)
Item Control Parameter
