Master
537
XL8 Live Performance System
Owner’s Manual
Insert
The following diagram shows the parameters of the insert section affected by stereo
linking.
Item
Control
Parameter
1
INS
swit
ch
Insert in
/out
Insert and configuration
processing area in GUI
channel strip
master overview in
GUI channel strip
1
562
564
