Aux Sends (1 to 16)
This section shows the parameters of the input channel mix sections copied through
scenes.
Note: Only aux sends 1 to 8 are shown above, but this is typically the same for all of
the 16 aux sends.
Item Control Parameter
1 ON switch Bus send on/off
2 level/pan control
knob
Bus level, or pan when bus is linked
3 PRE switch Pre-fader on/off
4 level control knob Bus level
5 On switch Aux bus send on/off — only available when aux
bus is in group mode
6 MINUS switch Aux bus send mute on/off — only available when
aux bus is in mix minus mode
1
3
1
3
2
4
1
3
1
3
1
3
Aux buses
processing area in
GUI channel strip
1
3
GUI input
fast strip
input channel
overview in GUI
channel strip
5
6
