Milestone LOGOS One - Page 23

Milestone s.r.l.
MM098-002 – LOGOS ONE – Operator Manual
23
Press “Settings” to access the administrator screen.
Then press “Owner” and choose the “Remote Connection” tab:
Select “Specify an IP address”. Enter the data required supplied by the Network Administrator.
For example:
IP Address
192.168.1.235
Subnet Mask
255.255.255.0
Default Gateway add.
192.168.1.6
DNS server address
192.168.1.7
WINS
Not required
Each time you click on a white box, a num-pad appears; enter the number required and press enter. Fill all
the white boxes with the data network. At the end Press HOME button to store the data.
