The arm spring can be adjusted as explained in the previous chapter.
Join the VESA plate to the keyboard support, as per photo, with the supplied screws, making sure to direct it
as shown by the arrow in the following figure.
Adjust the arm frictions according to the instructions below. Act on the screws indicated in the following figure
to modify the frictions.
Use a 3 mm Allen wrench. Rotate clockwise to reduce the force. Rotate anti-clockwise to increase the force.
