Milestone UltraGROSS - Clearance Requirements for Initial Code with 150

UltraGROSS
MM182-001 – Operator Manual
31
2.3. Clearance requirements for initial code with 150
UltraGROSS is shipped in a wooden crate weighing 260Kg (573.2lb). For the overall weight (unit + crate) see
chapter 1.3.3.
Dimensions:
Width: 207cm (81.49”)
Height: 190cm (74.80”)
Depth: 127cm (50”)
The crate is equipped with a ramp to unload the unit which requires a clearance space of 6 m to be used.
Unit dimensions:
Dimensions if letter A: WxDxH 150cm x 81cm x 162cm (maximum height 192cm).
WxDxH 59.05” x 31.88” x 63.77” (maximum height 75.59”).
Dimensions if letter P: WxDxH 150cm x 81cm x 174cm (maximum height 204cm).
WxDxH 59.05” x 31.88” x 68.50” (maximum height 80.31”).
Dimensions if letters A and C WxDxH 158cm x 81cm x 162cm (maximum height 192cm).
WxDxH 62.2” x 31.88” x 63.77” (maximum height 75.59”).
Dimensions if letters P and C WxDxH 158cm x 81cm x 174cm (maximum height 204cm).
WxDxH 62.2” x 31.88” x 68.50” (maximum height 80.31”).
Space required to position the unit, measurements to be added to the dimensions of the unit itself:
- Unit with letter A: width 178cm – 70.07” (5cm – 1.96” side without keyboard support, 15cm – 5.90” side with
keyboard support); depth 19cm – 7.48”.
- Unit with letter P: width 178cm – 70.07” (5cm – 1.96” side without keyboard support, 15cm – 5.90” side with
keyboard support); depth 15cm – 5.90”.
At this point the UltraGROSS unit can be placed in its final position for use.
Add 10 cm in width if there are the Support for keyboard with clipboard or the Side support
for monitor and keyboard (as shown in chapters 5.24 and 5.23).
If the optional VIROCLEAN part (shown in chapter 5.31) is present, add 25cm in width.
If the optional Top support for monitor (shown in chapter 5.22) is present, add 20cm to the
height of the machine (excluding the height of the monitor).
