2.2. Clearance requirements for initial code with 180
UltraGROSS is shipped in a wooden crate weighing 260kg (573.2lb). For the overall weight (unit + crate) see
chapter 1.3.3.
Dimensions:
Width: 207cm (81.49”)
Height: 190cm (74.80”)
Depth: 127cm (50”)
The crate is equipped with a ramp to unload the unit which requires a clearance space of 6 m to be used.
Unit dimensions:
Dimensions if letter A: WxDxH 180cm x 81cm x 162cm (maximum height 192cm)
WxDxH 70.86” x 31.88” x 63.77” (maximum height 75.59”)
Dimensions if letter P: WxDxH 180cm x 81cm x 174cm (maximum height 204cm)
WxDxH 70.86” x 31.88” x 68.50” (maximum height 80.31”)
Dimensions if letters A and C WxDxH 188cm x 81cm x 162cm (maximum height 192cm)
WxDxH 74.01” x 31.88” x 63.77” (maximum height 75.59”)
Dimensions if letters P and C WxDxH 188cm x 81cm x 174cm (maximum height 204cm)
WxDxH 74.01” x 31.88” x 68.50” (maximum height 80.31”)
Dimensions if letters A and double letter C WxDxH 196cm x 81cm x 162cm (maximum height 192cm)
WxDxH 77.16” x 31.88” x 63.77” (maximum height 75.59”)
Dimensions if letters P and double letter C WxDxH 196cm x 81cm x 174cm (maximum height 204cm)
WxDxH 77.16” x 31.88” x 68.50” (maximum height 80.31”)
Space dimensions required to place the unit:
- Unit with letter A: width 208cm – 81.88” (5cm – 1.96” side without keyboard support, 15cm – 5.90” side with
keyboard support); depth 19cm – 7.48”.
- Unit with letter P: width 208cm – 81.88” (5cm – 1.96” side without keyboard support, 15cm – 5.90” side with
keyboard support); depth 15cm – 5.90”.
- Unit with letter A and double letter C: width 226cm – 88.97” (15cm – 5.90” both sides); depth 19cm – 7.48”.
- Unit with letter P and double letter C: width 226cm – 88.97” (15cm – 5.90” both sides); depth 15cm – 5.90”.
At this point the UltraGROSS unit can be placed in its final position for use.
Add 10cm in width if there are the Support for keyboard with clipboard or the Side support
for monitor and keyboard (as shown in chapters 5.24 and 5.23).
If the optional VIROCLEAN part (shown in chapter 5.31) is present, add 25cm in width.
If the optional Top support for monitor (shown in chapter 5.22) is present, add 20cm to the
height of the machine (excluding the height of the monitor).
