2.5.13. Connection to the fixative drain system
For letters that refer to unit codes, see chapter 1.3.1.
Only for letter D.
In UltraGROSS you may empty the fixative from the containers before specimens grossing.
10L TANK FOR USED FIXATIVE
Position the supplied empty 10L waste tank on the tank support, leaving the drain plug in the front as shown
in the photo.
Positions different than those mentioned above could damage the used fixative level
sensor.
Maximum dimensions of waste tank: WxDxH 200x210x325mm.
Position the fixative waste tank on the tank support in front of the new fixative tank.
Screw the fixative drain plug to the supplied 10L empty tank.
The cap thread on the tank is S55.
Check that the funnel is positioned below the fixative dispenser on the work surface.
The figure shows how to plug the tank with a specific stop by using the knob.
