3-CONTROLSANDINSTRUMENTS
Monitoringgaugeselection
ThemonitoringgaugesdisplayedontheA-Postdisplayscreenmaybechangedtosuittheneedsoftheoperator.
Themonitoringgaugesareselectablefromapop-upmenu.
Theselectionsforthemonitoringgaugesare:
•
Engineoilpressure
•
Turboboostpressure
•
Engineoiltemperature
•
Enginepercentloadandcurrentspeed
•
Intakemanifoldtemperature
•
Actualenginepercentagetorque
•
Enginecoolanttemperature
•
Hydrostaticchargepressure
•
Auxiliarypumppressure
•
Brakesupplypressure
•
Hydraulicoiltemperature(tank)
Tochangetheindividualmonitoringgauges,touchtheap-
propriategaugeselection(1through4),1beingthegauge
farthesttotheleft(1).
Thepop-upmonitoringgaugeselectionmenuappears.
RAIL17SP00107FA3
Usethepop-up"Bargraphs"menutoselecttheappropri-
ategauge(1through4).
Thegaugeselectionpop-upmenuappears.
RAIL17SP00110AA4
3-56
