Lubricatetheupperliftarmassemblypivots
Locatethegreasettingontheframeendofupperlift
armassembly(1)andthecenterboomendofeachside
oftheupperliftarmassembly(2).Cleanoffthegrease
ttingbeforeattachingthegreasegun.Greaseuntil
greasecomesoutofeachpivot.Wipeupanyexcess
grease.Repeatfortheothersideoftheupperliftarm
assembly.
RAIL17SP00304AA23
RAIL17SP00305AA24
Lubricatelowerliftarmcylinderpins
Locatethegreasettings(1)ontherodendsofthe
lowerliftarmcylinders(2)wheretheyattachtothelower
liftarm.Cleanoffthegreasettingbeforeattachingthe
greasegun.Greaseuntilgreasecomesoutofeach
pivot.Wipeupanyexcessgrease.Repeatfortheother
cylinder.
RAIL17SP00271AA25
Lubricatethesteeringkingpins
DANGER
Pinchhazard!
Keepyourhands,feet,andbodyclearofallmovingpartsandoscillatingpoints.
Failuretocomplywillresultindeathorseriousinjury.
