Miller Nitro 7310 - Every 400 Hours; Replace Hydraulic Oil Filter

7-MAINTENANCE
Every400hours
Replacehydraulicoillter
WARNING
Burnhazard!
Donothandleanyserviceuid(enginecoolant,engineoil,hydraulicoil,etc.)attemperaturesthat
exceed49°C(120°F).Allowuidstocoolbeforeproceeding.
Failuretocomplycouldresultindeathorseriousinjury.
W0330B
Thisprocedureisvalidforboththereturnlter(1)and
thecasedrainlter(2).
1.Drivethevehicleontoahard,levelsurface.
2.Shutoffthevehicleengineandremovethekeyfrom
theignition.
3.Allowtheengineandsurroundingcomponentstocool
beforeservicing.
4.Accessthehydraulicoiltankthroughtheenginecom-
partmentslidingdoor.Theoilltersareattachedtothe
topofthehydraulictank.
5.Removetheboltsaroundtheltercap.Removethe
lterelementfromthelterhousing.
6.Replacetheelementwithanewelement.Besureto
reinstallallgaskets.IfgasketsorO-ringsaredeterio-
rated,replacewithnewparts.
7.Replacethelterassemblyintothehousing,being
carefultolineituptoproperlyseatthelterassembly
inthehousing.
8.Placetheholdingspringonthehubofthecap.Make
suretoreinstalltheO-ringseal.Reinstallthecapand
tightenthebolts,beingsurethespringandO-ringare
properlyseatedsothesuctionltersealstothefaceof
thelterhousing.
RAIL17SP00262AA1
Torquethe5/16inchboltsto:19N·m(170lbin).T orque
the3/8inchboltsto:34N·m(25lbft)
