Miller Nitro 7310 - Boom Caster Wheel (if Equipped)

To Next Page

To Previous Page

10-ACCESSORIES

Boomcasterwheel(ifequipped)

Theboomcasterwheelmountedtotheouteredgeof

themonoboombreakaway,preventstheouteredgeof

theboombreakawayfromhittingtheterrain.Thecaster

wheelwillguidethebreakawaytip,overthecontourof

theterrain.

RAIL17SP00635AA1

10-7
