7-MAINTENANCE

Lubricateladderpivot

WARNING

Unexpectedmovement!

Stayclearwhenloweringtheladder.

Failuretocomplycouldresultindeathorseriousinjury.

W0911A

1.Locatetheladderliftcylinder.Thecylinderislocated

underthewalkwayplatformatthetopendoftheladder.

RAIL17SP00242AA1

2.Locatethegreasetting(1)attachedtothebaseend

oftheladderliftcylinder.

3.Cleanthegreasettingbeforeattachingagreasegun.

4.UseNEWHOLLANDAMBRAGR75MD.Lubricate

untilgreasecomesoutofthepivotjoint.

5.wipeupanyexcessgrease.

RAIL17SP01023AA2

7-61
