Miller Nitro 7310 - Machine Components

To Next Page

To Previous Page

1-GENERALINFORMATION

Machinecomponents

RAIL17SP00706FA1

1.Operator’scab

7.Ladder

2.Handrinsewatertank8.Planetary

3.Producttank9.Fueltank

4.Chemicalinjectiontanks(ifequipped)10.Operator’splatform

5.Boomrest

11.Liftarms

6.Enginecompartment12.Frontboomcentersection

1-9
