Miller Nitro 7310 - Wheel Lug Nut Torque

To Next Page

To Previous Page

7-MAINTENANCE

Wheellugnuttorque

Checkthewheellugnuttorque.Torquethelugnutsto

610N·m(450lbft).

Re-torquethewheellugnutseachtimeawheelisrein-

stalledontothevehicle.Checkandre-torquethelugnuts

againafteronehourofuse.

RAIL15SP00828AA3
