7-MAINTENANCE

1.Locatethegreasettingoneachofthefrontsteering

pivotkingpintubesandrearsteeringpivotkingpin

tubesona4wheelsteermodel..

2.Cleanoffgreasettingsbeforeattachingthegrease

gun.

3.UseNEWHOLLANDAMBRAGR75MD.Greaseall

thettingsuntilgreasecomesoutofthekingpintube.

4.Wipeupexcessgrease.

RAIL17SP00255AA1

Lubricatethesuspensioncomponents

DANGER

Pinchhazard!

Keepyourhands,feet,andbodyclearofallmovingpartsandoscillatingpoints.

Failuretocomplywillresultindeathorseriousinjury.

D0206A

1.Locatethegreasettingoneachoftheswingarmpin

tubes(totalof4permachine).

2.Cleanoffgreasettingsbeforeattachingthegrease

gun.

3.UseNEWHOLLANDAMBRAGR75MDandlubricate

allthettingsuntilthegreasecomesoutofthepivotpin

tube.

4.Wipeupexcessgrease.

RAIL17SP00301AA1

7-59
