Miller Nitro 7310 - Cooling Fan Icon and Screens

3-CONTROLSANDINSTRUMENTS
CoolingFaniconandscreens
Fromthearmrestdisplaysecondhomepagetouchthe
coolingfanicon.
Thisscreenisusedtochangethereversingtimeinterval
aswellasthelengthoftimeitwillreverse.
NOTE:ThefanwillnotreverseatlowengineRPM.
Fromthisscreenyoucanchangetheautotimeinterval
(1),thereversetimeinterval(2)bytouchingtheappro-
priateicontobringuptheadjustmentscreens.Adjustas
desiredusingtheupordownarrows(3)onthesetting
screen.T oleavetheadjustmenttouchtheselectedicon
again.
Oncethetimesareset,theright-handsideofthescreen
willactasacountdownfromtheoriginalsetvalues.The
AutoTimeIntervalandtheReverseTimeIntervalwillboth
countdown.
RAIL17SP00109FA1
RAIL17SP00195AA2
Touchthe“Disable”reversingfan(4)icon(lowerleft)to
disablethefansreversingability.Touchthemanualover-
ride(5)icon(lowerright-handicon)tomanuallyoverride
thesettingsandturnthereversingfeatureon.Pressit
againtoreturntonormaloperation.
Touchthe“Fan”(6)icon(belowthehomeicon)tosetthe
fanspeedto100%.Fanisinautomodeunlessthefan
iconispressed.Whentheiconistouchedthefanwillturn
yellowandpercentagewillbesetto100%.
Touchthehomeicon(7)toreturntothehomepage.
RAIL17SP00195AA3
Thereversingfanoverrideswitch(1)onthesideconsole
isusedtooverridetheautomaticsettingofthereversing
fan.
Ifthecoolingsystembecomescloggedwithdebrisandthe
automaticsettinghasnotyetengaged,pushtheoverride
switchandthereversecyclewillinitiate.
