6-WORKINGOPERATIONS
Spraysystemoperation
Beginsprayingoperation
DANGER
Electrocutionhazard!
Contactwithoverheadpowerlinescancausesevereelectricalburnsordeathfromelectrocution.
Makesurethereisenoughclearancebetweenequipmentandoverheadpowerlines.
Failuretocomplywillresultindeathorseriousinjury.
D0024A
WARNING
Lossofcontrolhazard!
Travelspeedshouldbesuchthatcompletecontrolandmachinestabilityismaintainedatalltimes.
Wherepossible,avoidoperatingnearditches,embankmentsandholes.Reducespeedwhenturning,
crossingslopes,andonrough,slick,ormuddysurfaces.
Failuretocomplycouldresultindeathorseriousinjury.
W0233A
Forfactorysuppliedsprayercontrollers,refertothespeciccontrollersoftwareoperatingguideforallset-upproce-
dures.
Raven™settingprocedure
RefertoyourRaven™Operator’sManualforinformationonhowtoprogramyourRaven™console.TheRaven™
consolehasbeenpre-programmedatthefactory.UsetheseproceduresandsettingsinconjunctionwiththeRaven™
manualtoresetitifneeded.
NOTE:Thesprayercoolingsystemoperatesmostefcientlyathighidle.Itisrecommendedtooperateathighidle
tomaximizecoolingsystem.
NOTE:Maximumsprayingspeed32km/h(20mph).
1.Openproducttanksump.
2.Turnontheproductpumpandthespraymonitor.
3.Turnontheboomsections(2).Generallyalltheboom
sectionswillbeon.Whenreachingtheedgeofthe
elditmaybenecessarytokeeptheoutersectionsoff,
toavoidoverspraying.Thisisaccomplishedwiththe
individualboomsectionon/offbuttonsonthejoystick.
4.Usethecenterlift(5)andtheright-hand(6)andleft-
hand(4)tiltcylinderstolowertheboomtotheheight
speciedbythenozzlesselected.
5.Turnonthefoammarker(3)andselectthedesired
sideusingtheturnsignalcontrolleverormulti-function
button.Adjustthefrequencyand/orthedensityas
requiredonthedisplaymonitor.
RAIL17SP00391AA1
6.Shutoffalltheboomsectionswiththemasterswitch
(1)whenyoureachtheendoftheeld.
7.Turnoffthefoammarker.
8.Afterturningaroundandgettingreadyforthereturn
pass,turnthemasterswitch(1)backontoresume
spraying.Anyboomsindividuallyoffbeforeturning
themasterswitchoff,willremainoffwhenspraying
resumes.
9.Turnonthefoammarkerandselectthecorrectside
usingtheturnsignalcontrollever.
6-26
