5-TRANSPORTOPERATIONS
Usethejoystickcontroltolowerboomagainstthetrans-
portstops.
1.Completelyraisetheleft-handandright-handbooms
usingtheleft-handtiltraisebutton(1)andtheright-
handtiltraisebutton(2)onthejoystick.
2.Lowertheboomcentersectiondownagainstthetrans-
portstopsontheliftcylindersusingthecentersection
raise/lowerbutton(3)onthejoystick.
3.Lowertheleft-handandtheright-handboomsback
intothetransportsaddlesusingtheleftandrightraise/
lowerbuttons(1)(2).Loweruntilalltensionisoffthe
tiltcylinders.
RAIL17SP00391AA6
Transportpreparationnalprocedure
1.Rotatetheamberrotatingbeaconsintothestorage
position.
Loosentheretainerthumbscrewlocatedonthewarn-
inglightpostandrotatetheentirepostwithbeacon
rearward.Tightenthethumbscrewtoholdthelightin
itsstoredposition.
2.Drivethevehicleontoaproperlysizedtrailer.
3.Placethejoystickcontrolintheneutral(N)positionand
applythevehicleparkingbrake.Turnoffthevehicle
engine.
4.Securethevehicletoatrailer.Tiedownthevehicleto
thetrailerusingthefourcornertiedownmethod.
Refertolocallawfortiedownmethodsinyourarea.
Securetiedownstotheprovidedtiedowneyesand/or
loops,butnevertovulnerableareassuchascylinder
rodsorsheetmetalareas.
Therearefourtiedownareasonthechassis;therear
tiedownloops(1),andthefronttiedownslots(2).
Thefronttiedownslotsarelocatedneartheliftarm
cylinderbaseend(3).
RAIL17SP00242AA7
RAIL17SP00256AA8
