6-WORKINGOPERATIONS

Achemicaleductorisavailableforllingtheproducttank

withtherequiredchemicalsfromthegroundlevel.

NOTE:Shutalltheboomcontrolsoffbeforeoperatingthe

chemicaleductor.

1.Filltheproducttankwith757–1893l(200–500US

gal)ofwater.Referto6-35.

2.Unlatchandlowerthechemicaleductordoordownto

theoperatingposition.

3.Pressproducttanksumpbutton(1)toopentheprod-

ucttanksump.

RAIL17SP00873AA1

4.Pressproductpumpbutton(1)tostarttheproduct

pumpandmaintainatleast50psisystempressure.

RAIL17SP00873AA2

6-40
