7-MAINTENANCE
Enginefuse/relayblock
TheEnginefuse/relayblock(1)islocatedbehindtheleft-
handsidepaneloftheenginecompartment.
Removethepanelbypullingthegrabhandleoutward,and
thenliftingthepanelupwardtoremovefromthevehicle.
Reinstallthepanelbeforeoperatingthevehicle.
RAIL17SP00370AA2
ThefusesandrelayslocatedontheEnginefuse/relayblockarelistedinthetable.
Fusenumber
RelaynumberAmperage
Description
F1K110A
BoomRest—UpLights
F2K210A
BoomRest—LeftOutLight
F3K320A
Spare
F4K410A
BoomRest—RightOutLight
F5K520A
Spare
F6K610A
EngineControlModule(ECM)SwitchedPower
F7K720A
Spare
F8K815A
Spare
F9K915A
Air-conditioningclutch
—
K10
-
Spare
—
K11
-
Spare
—
K12
-
Spare
—
K13
-
Spare
—
K14
-
EngineAuxiliaryRelay
—
K15
-
Spare
F10
—
20A
Spare
F11
—
10AFoamerPower
F12
—
15A
SensorPower
F13
—
25AProductValves
F14
—
15ANodePower
F15
—
15ABoomValves
F16
—
20A
ControlNodesHighCurrentpower
F17
—
15A
Spare
F18
—
10AAlternatorExciter
F19
—
30A
InjectionHighCurrentPower#2
F20
—
30A
InjectionHighCurrentPower#3
F21
—
30A
InjectionHighCurrentPower#1
F22
—
30A
EngineControlmodule(ECM)Constantpower
F23
—
20A
ISOBUSConstantpower
F24
—
10A
EgressLights
F25
—
25A
IntelliSpray™HighCurrentPower#1
F26
—
25A
IntelliSpray™HighCurrentPower#2
F27
—
25A
IntelliSpray™HighCurrentPower#3
F28
—
20A
EngineAuxiliaryRelayPower
F29
—
25A
IntelliSpray™HighCurrentPower#4
