2-SAFETYINFORMATION

Safetysign14—35.03616

Operatorwarningscabinteriorright-handside

Locatedinsidecabonrightsidecabpillartotherear

ofrightsidewindow

(quantity1)

RAIL17SP00713BA17

WARNING

Tip-overhazard.Alwayswearseatbelt

Onlystartenginefromoperatorsseatwithparkbrake

engaged.

Emergencyexit.breakglasstoexit.

Failuretocomplycouldresultindeathorseriousinjury.

2-26
