3-CONTROLSANDINSTRUMENTS

Onthesecondhomepagetouchthedisplaysicon(1).

Thiswillbringupthemainscreenwhereyouselectoper-

atorsettings(2).

RAIL17SP00109FA33

RAIL17SP00143AA34

Touchthefencerowicon(3)Thiswillbringupthefence

rowmodeicon(4)Tohavetheleftorrightfencerownoz-

zleturnonautomaticallywiththeoutermostsection,you

mustturnthatfeatureonbyselectingtheautoicon(5).

RAIL17SP00144AA35

RAIL17SP00152AA36

3-23
