3-CONTROLSANDINSTRUMENTS
Roadheadlightsswitch
Theroadheadlightswitch(1)turnstheroadheadlights
locatedinthefrontfendersonandoff.Presstheswitch
toturntheroadheadlightson.Presstheswitchagainto
turntheroadheadlightsoff.
Stadiumlightsswitch
Thestadiumlightsswitch(2)turnsthesixstadiumlights
locatedatthefrontofthecabonandoff.Presstheswitch
toturnallsixofthestadiumlightson.Presstheswitch
againtoturnallthestadiumlightsoff.
Boomlightsswitch
Theboomlightswitch(3)turnstheboomlightsonoroff.
Theboomlightsarelocatedintheboomcentersection,
andontheleft-handandright-handboomrests.
Presstheswitchtoturntheboomlightson.Pressthe
switchagaintoturntheboomlightsoff.
RAIL17SP00263AA5
Egresslightsswitch(ifequipped)
Theegresslightsareactivatedbypressingtheegress
lightswitch(1).Theselightswillcomeonandstayon
whenswitchisactive.Theycanalsobeactivatedby
pressingtheoutsideegresslightswitch(2)locatedonthe
rearbottomedgeoftheenginecompartmenthoodand
placingthedomelightswitchtotheleft-handside.
Theegresslightsconsistofthelightspositionedonthe
loweredgeofthecabroofabovethedoor,thelightat
thefrontoftheenginecompartmenthousingabovethe
slidingdoorsandatthelowerleftrearcorneroftheengine
compartmenthousingabovetheladder.
RAIL17SP00263AA6
