2 System Overview
Operator’s Manual 2 - 13
5. Dual-split
window key
• In non-dual split mode, press to enter the dual split
mode.
• In dual split mode, press to switch the active window.
6. iHelper iHelper • Press to enter or exit iHelper.
• iHelper includes Remote Assistance, iScanhelper,
Quick Guide, and Operator's Manual.
7. Angle/
Multifunctional
knob
Angle/
Multifunctional
knob
Rotate to adjust image parameters or direction.
8. M/X M mode key • Press to enter or exit the M mode. When the M mode
is enabled:
– If the Mark is not displayed, then press to
display the Mark line;
– If the Mark is displayed, then press to enter M
mode.
• Rotate to adjust M gain; while in 3D/4D mode, rotate
the knob to make the 3D image rotate around X axis.
9. Update key • Switch the current active window in multi-windows
mode.
• Complete the image acquisition in iScape/3D/4D
mode etc.
10. B B mode key • Press to enter the B mode.
• Rotate to adjust the B or 3D/4D gain.
11. Depth/Zoom Depth/Zoom • Adjust the image depth.
• Press to enter or exit zoom status.
12. Body Mark / Press to enter or exit Bodymark status.
13. ABC Comment key Press to enter or exit Comment status.
14. Measure Measure key Press to enter/exit the application measurement mode.
15. Caliper Caliper key Press to enter/exit the general measurement mode.
16. iTouch
+
iTouch
+
key • Press to optimize the images, and keep pressing to
further optimize the image.
• Long press or double press to exit iTouch
+
.
17. P1 User defined
key
Set by the user in the Preset.
18. Clear Clear key • Press to clear in the sequence of “the selected
measurement and comment information”, “screen
information of the current application mode”, and
then “all measurement and comment information”
• Long press to clear all the measurement and
comment information on the screen.
19. Cursor key Press to show/hide the cursor.
20. / Confirm key
(left<Set>key)
Press to confirm the operation.
